MODEL | Apex | 6000mm x 7000mm
£3,510.00 inc. VAT
Redwood Open Shelter
☑️ 40mm x 76mm Treated Framing
☑️ 21mm Redwood Cladding
All prices inclusive of VAT
Base unit external footprint size - 6000mm (Gable) x 7000mm
Height info - 2080mm through doors/eaves - Standard
Highest point to ridge - 3000mm
(Please see below for alternative options).
FRAME - C16 CLS 40MmmX 76mm - (see below for alternative options)
ROOF - Genuine ONDULINE roof (Sheets, fixings) 15 year guarantee & light weight black plastic coated tin ridge tops to give extra life to roof.
PURLINS - C24/26 (4x2)/(6x2) inch (Pressure tested dry graded)
FRAMING FIXINGS - Heavy duty twin thread Zinc 100mm fixings
PLINTH/RING BEAM - 60mm x 40mm” High pressure treated Redwood sleepers to ensure maximum life span and substantial floor support.
EXTERIOR CLADDING - Custom SHEDBOX profile - Imported Scandinavian Redwood Tantalised half-lap - 21mm - Applied with 40mm ring-shank coil nails. 18 points along the clad
WHY REDWOOD? Abundant, renewable and energy-efficient. Redwood is clearly the environmental choice
GROUND ANCHOR KIT - (Thunder bolts concrete screws secured into the concrete 175mm mm fixings) - Secures building to the concrete floor & now means the building can be damp sealed - Ask for more information. Ground anchor kits are required on all porch/overhang upright posts to ensure position fixture.
ROOF BOARDING (INCLUDED ON ALL ORDERS)- 9mm 2397 x 1197 Kronospan OSB3
ROOF SEAL KIT - Seals roof sheets to panel tops (eves) Foam inserts that are machined in 1meter lengths to fit the roof profile perfectly. Ideal for keeping heat in and finishing off the overall look.
SELF BUILD - The building would arrive in pre-fabricated panels with all the materials required to complete and would be delivered by one of our qualified joiners who would go through the full erection process with you. All panels & apex's are tradesman built with exceptional quality and workmanship.
DELIVERY NOT INCLUDED, PLEASE SEE BELOW:
Delivery is charged at £2.50 per mile, one way from our Shropshire workshop to your address. Once you have placed your order you will need to send us a message with your full address, post code, contact telephone number and email address, we will then notify you of the additional delivery charge.
Please be aware that as our workshop is based in Shropshire therefore they may be a surcharge if your location requires our driver to stay overnight due to driving restrictions.
All of our buildings are made to order therefore the lead time from order confirmation to delivery is currently 4 weeks
ALTERNATIVE SPECIFICATION OPTIONS
Building height options:
- 1800mm (EAVES) 2500mm (RIDGE)
- 2080mm (EAVES) 3000mm (RIDGE) - Included with this building
- 2450mm (EAVES) 3350mm (RIDGE)
External Redwood cladding options:
- 21mm - Included with this building
Carsassing frame options:
- 40mm x 76mm - Included with this building
- 40mm x 90mm
(If you would like to upgrade your building to any of the above options please contact us).
40mm x 60mm
|Double Door Width||
No Double Doors
|Personnel Door Width||
No Personnel Door
Onduline Corrugated Sheet
