Model | APEX

Base unit external footprint size - 5000mm (Gable) x 7000mm

Panel height - 2080mm

Overall height - 3000mm

(Please see below for alternative options).

FRAME - C16 CLS 40mm x 90mm

ROOF - Genuine ONDULINE roof (Sheets, fixings) 10 year sheet guarantee.

PURLINS - C24/26 40mm X 90mm

FIXINGS - FRAME - 100mm Ring shanked framing nails | CLADDING - 40mm ring shanked nails

PLINTH/RING BEAM - 90mm x 40mm High pressure treated Redwood sleepers to ensure maximum life span and substantial floor support.

EXTERIOR CLADDING - Custom SHEDBOX profile  - Scandinavian Redwood Tantalised half-lap - 125mm (width) x 22mm

WHY REDWOOD? Abundant, renewable and energy-efficient. Redwood is clearly the environmental choice

PLINTH BEARERS - (Ensurers full life of shed by lifting untreated framing timbers off the ground) - Pressure treated red wood ring-bead tailor machined to fit your specific building size. Fully supported floors can now be added to orders with this option selected

GROUND ANCHOR KIT - (Thunder bolts concrete screws secured into the concrete 175mm mm fixings) - Secures building to the concrete floor & now means the building can be damp sealed - Ask for more information. Ground anchor kits are required on all porch/overhang upright posts to ensure position fixture.

ROOF BOARDING (INCLUDED ON ALL ORDERS) - 12mm 2397 x 1197 Kronospan OSB3

WATERPROOF MEMBRANE - Made of high density polyethylene fibres for long-term protection against the elements. This durable, lightweight breathable membrane is windtight and water resistant and designed for use in external timber garden buildings.

FLOORING - 40mm x 40mm Treated Redwood support timbers. 18mm Hexa Birch core with plastic coated non-slip finish.

FULLY FRAMED HEAVY DUTY DOUBLE DOORS (2x1200mm) - x2 Sets - Complete with all heavy duty irons inside and out. Galvanised then power-coated in Black

FULLY FRAMED HEAVY DUTY SINGLE ACCESS DOOR (850mm) - Complete with all heavy duty irons inside and out. Galvanised then power-coated in Jet Black

TIMBER WINDOWS - Model WF3 - x3 - and Model WFR2 - x2 - Machine regulated & morticed jointed - GLASS NOT INCLUDED

ROOF SEAL KIT - Seals roof sheets to panel tops (eves) Foam inserts that are machined in 1meter lengths to fit the roof profile perfectly. Ideal for keeping heat in and finishing off the overall look.

FLOOR/PLINTH SEAL KIT - Seals your pressure treated plinth to your concrete base. Includes a waterproof gap sealant (clear), gun for application and re-useable sealant edging kit.

HIGH FLOW GUTTER KIT - (High flow Black) Will prevent rain water collecting around the base of the shed thus keeping water damage to a minimum around the base.

SELF BUILD BASIS - The building would arrive in pre-fabricated panels with all the materials required to complete and would be delivered by one of our qualified joiners who would go through the full erection process with you. All panels & apex's are tradesman built with exceptional quality and workmanship.

INSTALLATION SERVICE - We do offer a full installation across our entire range, for more information please contact us

DELIVERY NOT INCLUDED, PLEASE SEE BELOW:

Delivery is charged at £2.50 per mile, one way from our Shropshire workshop to your address. Once you have placed your order you will need to send us a message with your full address, post code, contact telephone number and email address, we will then notify you of the additional delivery charge.

Please be aware that as our workshop is based in Shropshire therefore they may be a surcharge if your location requires our driver to stay overnight due to driving restrictions.

All of our buildings are made to order therefore the lead time from order confirmation to delivery is currently 4 weeks

ALTERNATIVE SPECIFICATION OPTIONS

Building height options:

- 1800mm (EAVES) 2500mm (RIDGE)

- 2080mm (EAVES) 3000mm (RIDGE) - Included with this building

- 2450mm (EAVES) 3350mm (RIDGE)

(If you would like to upgrade your building to any of the above options please contact us).
