Workshop | Store Room

3000mm x 5000mm

Original price was: £4,303.90.Current price is: £4,048.15. inc. VAT

Cladding Type Redwood
Roof Type Pent
Roofing Material Onduline Corrugated Sheet
Made to order in the UK
Nationwide delivery & installation
Bespoke specifications available
Groundworks available
Electrics available
Design, build & installation
Get a Quote → Call 01948 807000
One team from groundwork to electrics. ShedBox can manage the complete project.
FULL SPECIFICATION

Want to see the construction details?

Everything from framing and flooring to roofing, doors and windows is set out below.

Detailed Specs

Building Dimensions

External Building Footprint
3000mm x 5000mm
3000mm gable width

Roof Type
Pent

Front Height
2500mm

Rear Height
2300mm

Construction Specifications

Frame

C16 CLS pressure-treated timber, 40mm x 90mm.

Roof Covering

Low-maintenance EPDM rubber roofing, resistant to ozone, UV radiation and ageing. Remains flexible down to -45°C and can elongate by over 300% to accommodate building movement and temperature changes.

Purlins

C16/C24 pressure-treated timber, 40mm x 140mm.

Fixings

Frame: 100mm ring-shanked framing nails.
Cladding: 40mm ring-shanked nails.

Plinth / Ring Beam

C16 treated timber, 40mm x 90mm, providing durability and substantial floor support.

Exterior Cladding

Custom ShedBox profile, tanalised Scandinavian Redwood half-lap cladding, 125mm wide x 22mm thick, with a castle profile. Fitted vertically.

Roof Boarding

18mm Kronospan OSB3 boards, 2397mm x 1197mm.

Flooring

50mm x 90mm pressure-treated timber joists supported on battens to allow airflow. Finished with 18mm Hexa birch-core flooring with a plastic-coated, non-slip surface.

Waterproof Panel Membrane

Lightweight, breathable membrane made from high-density polyethylene fibres. Wind-tight and water-resistant, with high water-vapour permeability (Sd value: 0.01m). Can be fitted directly to insulation and helps improve airtightness.
CE marked; BBA, IAB and UKAS approved. BBA certificate: 90/2548.

Doors & Windows

Heavy-Duty Double Garage Doors

2 x 1200mm
Fully framed, with heavy-duty ironmongery inside and out. Ironmongery is galvanised and powder-coated in Jet Black.
Includes a secure lock and key.

Additional Features

Plinth Bearers

Optional pressure-treated Redwood ring-beam bearers, machined to suit the building dimensions. Fully supported flooring can be added to orders when this option is selected.

External Corner & Roof Trim Kit

Anthracite Grey plastic-coated tin trims with an eased-edge profile, applied to external corners and roof edges.

Build & Installation

Self Build

Supplied in prefabricated panels with all materials required for assembly. Panels are built by skilled tradespeople, and a qualified joiner will explain the full assembly process when the building arrives.

Professional Installation

Available as an optional service. Please contact ShedBox for more information.
